HL型(带制动轮)弹性柱销联轴器基本参数和主要尺寸
型 号 | 公称扭距 Tn N·m | 许用转速[n] r/min | 轴孔直径 d1,d2, d3 | 轴孔长度 | D mm | 转动惯量 kg.㎡ | 质量 Kg | ||
Y型J,J1,Z1型 | |||||||||
钢 | 铁 | 钢 | 铁 | L,L1 | |||||
HL1 | 160 | 7100 | 12-24 | 12-22 | 27-52 | 90 | 0.0064 | 2 | |
HL2 | 315 | 5600 | 20-35 | 20-32 | 38-82 | 120 | 0.253 | 5 | |
HL3 | 630 | 5000 | 30-48 | 30-42 | 60-112 | 160 | 0.6 | 8 | |
HL4 | 1250 | 4000 | 2800 | 40-63 | 40-56 | 84-142 | 195 | 3.4 | 22 |
HL5 | 2000 | 3550 | 2500 | 50-75 | 50-70 | 107-142 | 220 | 5.4 | 30 |
HL6 | 3150 | 2800 | 2100 | 60-85 | 60-80 | 107-172 | 280 | 15.6 | 53 |
HL7 | 6300 | 2240 | 1700 | 70-110 | 70-100 | 107-212 | 320 | 41.1 | 98 |
HL8 | 10000 | 2120 | 1600 | 80-125 | 80-110 | 167-212 | 360 | 56.5 | 119 |
HL9 | 16000 | 1800 | 1250 | 100-140 | 100-130 | 167-252 | 410 | 133.3 | 197 |
HL10 | 25000 | 1560 | 1120 | 110-180 | 110-160 | 167-302 | 480 | 273.2 | 322 |
HL11 | 31500 | 1320 | 1000 | 130-220 | 130-190 | 202-352 | 540 | 555.7 | 520 |
HL12 | 63000 | 1250 | 950 | 160-260 | 160-220 | 242-410 | 630 | 902 | 714 |
HL13 | 100000 | 1120 | 850 | 190-300 | 190-260 | 282-470 | 710 | 1700 | 1057 |
HL14 | 160000 | 850 | 630 | 240-340 | 240-300 | 330-550 | 800 | 4318 | 1956 |
HLL(带制动轮)弹性柱销联轴器基本参数和主要尺寸
型 号 | 公称转距 Tn N·m | 许用转速[n] r/min | 轴孔直径 | 轴孔长度 | D0 | D | B | 转动惯量 kg.㎡ | 质量 Kg |
d1,d2, dz | Y型J,J1,Z1型 | ||||||||
mm | L,L1 | ||||||||
HLL1 | 315 | 5600 | 20-35 | 38-82 | 200 | 120 | 85 | 218 | 11 |
HLL2 | 630 | 5000 | 30-48 | 60-112 | 200 | 160 | 85 | 2.45 | 14 |
HLL3 | 630 | 1900 | 30-48 | 60-112 | 315 | 160 | 132 | 13.08 | 25 |
HLL4 | 1250 | 1900 | 40-63 | 84-142 | 315 | 195 | 132 | 16.6 | 40 |
HLL5 | 1250 | 1400 | 40-63 | 84-142 | 400 | 195 | 168 | 49.2 | 59 |
HLL6 | 2000 | 1400 | 50-75 | 84-142 | 400 | 220 | 168 | 57.6 | 69 |
HLL7 | 2000 | 1120 | 50-75 | 84-142 | 500 | 220 | 210 | 127.4 | 91 |
HLL8 | 3150 | 1400 | 60-85 | 107-172 | 400 | 280 | 168 | 161.7 | 88 |
HLL9 | 3150 | 1120 | 60-85 | 107-172 | 500 | 280 | 210 | 129.2 | 113 |
HLL10 | 6300 | 1120 | 70-110 | 102-212 | 500 | 320 | 210 | 156 | 156 |
HLL11 | 6300 | 960 | 70-110 | 102-212 | 630 | 320 | 265 | 314 | 187 |
HLL12 | 10000 | 960 | 80-125 | 132-212 | 630 | 360 | 265 | 328 | 326 |
HLL13 | 16000 | 800 | 100-140 | 167-252 | 710 | 410 | 298 | 713 | 337 |
HLL14 | 25000 | 800 | 110-180 | 167-302 | 710 | 480 | 298 | 849 | 458 |
HLL15 | 25000 | 710 | 110-180 | 167-302 | 800 | 480 | 335 | 1231 | 504 |
